ResTest 55
For multicore cables
The ResTest 55 is specially designed to measure the linear resistance of both multicore cables and smaller sections. This fully integrated equipment not only offers operating comfort, but also the mastering of all the uncertainties connected with the measurement.
Key Features
Specs and datasheet
Download
Key Features
- For both small conductors and multicore cables
- from very fine wires up to 50 mm2 (1/0 AWG) conductors
- Ideal for any type of conductor
- class 1 (rods & wires)
- class 2 (stranded conductors)
- class 5/6 (flexible conductors)
- sector-shaped conductors
- insulated conductors
- multicore cables
- Easy to use:
- self-cutting knives for both voltage and current contacts
- LED monitoring system
- interchangeable jaws
- direct readings in Ω/km @20ºC
- button or touchscreen
- embedded PC
- Overall accuracy: specifications related to the whole measurement, not the instrument only
Specs and datasheet
- For multicore cables and smaller sections.
- Cross-section: max. 50 mm²
- Conductor Ø : min 0.15 mm
- Measuring length: 1’000mm
- Minimum sample length: 1’700mm
- State-of-the-art interface thanks to a 7” touchscreen
- Ideal for any type of conductor
