High Frequency Parameters
Measuring High Frequency parameters involves monitoring data transfer in a communication cable (twisted pair or coaxial cable) as a function of frequency. These tests of increasingly complex copper cables are in accordance with the main international standards.
Key Features
Applicable Standards
How to get cable certification
Download
Key Features
Complete caracterization of High Frequency parameters:
- Insertion Loss (also called Attenuation)
- Return Loss
- Impedance
- Crosstalk (NEXT & FEXT) + Power Sum
- etc
Frequency range from 10kHz to 4.5GHz
For this test, a sample of 100 meters (328 ft) will be required.
Applicable Standards
- ANSI/TIA-568.2-D for Category 5, 5e, 6, 6a and 8
- IEC 61156-5/-10 for Category 5e to 8.2
- YD/T 1019/2013
How to get cable certification
- Get RFQ and place order
- Send sample
- Testing (optional live video conference)
- Evaluation
- Cable test report
Get your RFQ at service@aesa-cortaillod.com
